Picture of 5.0" HD 720 x 1280 Resolution Industrial TFT

5.0" HD 720 x 1280 Resolution Industrial TFT

Kyocera P/N: KII-050

*** UNDER DEVELOPMENT ***

Ship to

*

*

Shipping Method

Name

Estimated Delivery

Price

No shipping options

Qty:

Normally Black IPS, 600cd/m² LED Backlight, MIPI Interface

Please contact us for current availability.

Specifications

Products specifications

Country of Origin	China
Module Type	TFT
Diagonal Size	5.0"
Type	Transmissive
Display Mode	AWV - Normally Black
Resolution	720X1280
Brightness (cd/m2)	600
Contrast Ratio	800:1
Interface	MIPI
Vertical Viewing Angle:	-80/80
Horizontal Viewing Angle:	-80/80
Operating Temperature (C)	-20 to 70
Storage Temperature (C)	-30 to 80
Temperature	Standard Industrial Temp
Viewing Dir.	ALL
Outer Dimension (mm)	65.4 (W) x 118.9 (H) x 1.75 (D)
Backlight	LED
Touchscreen	None

Products specifications

Country of Origin	China
Module Type	TFT
Diagonal Size	5.0"
Type	Transmissive
Display Mode	AWV - Normally Black
Resolution	720X1280
Brightness (cd/m2)	600
Contrast Ratio	800:1
Interface	MIPI
Vertical Viewing Angle:	-80/80
Horizontal Viewing Angle:	-80/80
Operating Temperature (C)	-20 to 70
Storage Temperature (C)	-30 to 80
Temperature	Standard Industrial Temp
Viewing Dir.	ALL
Outer Dimension (mm)	65.4 (W) x 118.9 (H) x 1.75 (D)
Backlight	LED
Touchscreen	None
