Picture of 4.0" 480 x 800 WVGA Resolution Industrial TFT

Sorry - this product is no longer available

4.0" 480 x 800 WVGA Resolution Industrial TFT

Kyocera P/N: TCG040WVL

UNDER DEVELOPMENT - MP AVAILABILTY JUNE 2024

Qty:

Normally White TN, 900nits LED Backlight, CMOS Interface, High Bright

Please contact us for additional information.

Specifications

Products specifications

Module Type	TFT Digital
Diagonal Size	4.0"W
Type	Transmissive
Display Mode	AWV - Normally Black
Resolution	480X800
Brightness	900
Contrast Ratio	800:1
Interface	CMOS
Vertical Viewing Angle:	-80/80
Horizontal Viewing Angle:	-80/80
Operating Temperature (C)	-20 to 70
Storage Temperature (C)	-30 to 80
Temperature	Standard Industrial Temp
Viewing Dir.	12:00
Outer Dimension (mm)	58.74 (W) x 97.6 (H) x 4.2 (D)
Backlight	LED
Touchscreen	None

Products specifications

Module Type	TFT Digital
Diagonal Size	4.0"W
Type	Transmissive
Display Mode	AWV - Normally Black
Resolution	480X800
Brightness	900
Contrast Ratio	800:1
Interface	CMOS
Vertical Viewing Angle:	-80/80
Horizontal Viewing Angle:	-80/80
Operating Temperature (C)	-20 to 70
Storage Temperature (C)	-30 to 80
Temperature	Standard Industrial Temp
Viewing Dir.	12:00
Outer Dimension (mm)	58.74 (W) x 97.6 (H) x 4.2 (D)
Backlight	LED
Touchscreen	None
